  • Golden warrior GT3K
< >
  • Golden warrior GT3K

Golden warrior GT3K

product power:2.4KW（千瓦）

product capacity:3KVA 【View products of the same capacity】

series:High frequency GT series 【View the same series of products】

voltage input and output:Single in single out (220V:220V)

weight:27.5 kg（ 公斤）

size（LWH）:425*190*328 MM（毫米）8U

Shape classification:

  • Product Overview
  • For details
  • Installation Notes
  • Product Image
  • After-sales service
  • Documentation

    • GT3KDetailed parameter list

    capacity3KVA/2.7KW
    modelGT3K

    GT3KThe input parameters

    Rectifier typeIGBT rectifier
    The rated voltage220Vac
    Input voltage range115~300 VAC
    Input frequency range40Hz~60Hz（Adjustable)
    Input power factor>=0.99

    GT3KOutput parameters

    Rated output3KVA / 2700 W
    Rated output voltage220Vac
    The output frequency50/60 Hz +/- 0.5Hz
    Way to workon-line
    Output waveformSine wave
    Conversion time0ms
    Overload capacity125%，50s

    GT3KBattery and running time

    The battery modelMaintenance-free sealed lead-acid battery
    Mark the machine backup timeHalf-time: ≥11 minutes
    Battery pack model12V7AH
    Typical battery charging time8小時(shí)
    The battery voltage96V

    GT3KSystem parameters and standards

    installationtower
    The machine efficiencyUp to 90%
    Electromagnetic compatibilityICE/EN/AS 62040-1；CISPR 22 A級
    Surge protectionICE/EN 62040-2，滿(mǎn)足ICE/EN 61000-4-5
    防護類(lèi)型IP20

    GT3KCommunication and management

    Interface portsRS232，Interface ports
    The control panelLED status indicator
    LED status indicatorAlarm once every 4 seconds when mains power fails: special low battery alarm once every second

    GT3KPhysical index

    W425.00 mm
    D190.00 mm
    H328.00 mm
    weight27.50 KG
    colourblack

    GT3Ksurroundings

    working environment0 - 40 °C
    Relative humidity0 - 95%
    Operating height0-1500米
    storage temperature-5 - 45 °C
    Storage relative humidity0 - 95%
    Storage height0-15000m
    Audible noise at 1 m from the surface of the device<40.00 dB

    GT3KWarranty

    Standard warrantyRepair or replace within 3 years



    The backup machine adopts gb plug and socket, please use according to the instruction

    800×800
    Golden warrior GT3K

    Backup model: one year warranty built-in battery one year warranty


    Online model: 3-year warranty


    12V24AH capacity battery products: three-year warranty


    All over the country after sales service contact: contact us


    7*24 hour service tel: 400-830-8833
